Howo 430HP Tractor Head
Howo 430HP Tractor Head

Howo 430HP Tractor Head

31500 USD

Howo 430hp Tractor Head is Sinotruk inheriting the excellent characteristics of howo brand to adapt to the working conditions and cost-effective needs of China and developing countries.

Howo 430HP Tractor Head Price: 31500USD

The cylinder block of this sinotruk howo 430hp tractor head is made of vermicular graphite iron, the gantry frame, and the skirt part is designed with a spherical shape, and the connecting rod and crankshaft adopt the expansion and breaking process, which is guaranteed.

The front axle of the sinotruk howo 430hp tractor head has the functions of lightweight and heat dissipation, which is more advantageous than the current models of the same level in terms of comprehensive cost performance.  Modular design, reducing the number of parts by 25%, lower weight, and fewer failure points.

Howo Latest Model | Howo 430HP Tractor Head for Sale In NIgeria Lagos

Howo Latest Model | Howo 430HP Tractor Head for Sale In Nigeria Lagos

Howo Latest Model | Howo 430HP Tractor Head for Sale In NIgeria Lagos

Howo Latest Model | Howo 430HP Tractor Head for Sale In Nigeria Lagos

Howo Latest Model | Howo 430HP Tractor Head for Sale In NIgeria Lagos

Howo Latest Model | Howo 430HP Tractor Head for Sale In Nigeria Lagos



Specification of Howo Latest Model

Model: ZZ4257V3241W

Engine:

Engine model: D12.42-20, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinders in-line with water cooling, turbo-charging & inter cooling, mechanical high-pressure oil pump system

Maximum output: 430PS (309kW) at 2000 rpm

Maximum torque: 1820Nm at 1100-1400rpm

Bore: 126mm

Stroke: 155mm

Displacement: 11.596L

Clutch: SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance

Transmission:

Transmission, model HW19710, 10 forward and 2 reverse

Ratio: 4.42   4.8  5.73

Front Axle: New HF9 series, with drum brake system

Rear Axle: HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system.

Steering: ZF8118, hydraulic steering with power assistance

Ratio: 22.2-26.2:1

Dimensions inmm:

Wheel base (mm): 3200+1350

Front wheel track (mm): 2022/2041

Rear wheel track (mm):1830/1830

Overhang(front/rear) (mm):1500/725

Approach angle(°):16

Departure angle(°):70

Overall Dimension (mm): 6800x2496x2958

Wheels&Tyres:

Rims: 8.5-20,10 hole-steel

Types: 12.00R20 Option:12R22.4,12.00-24,12.00-20,13R22.5, 315/80R22.5, 295/80R22.5, 11.00R20

Driver'sCab: Long cab, all-steel forward control, 55°hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds, VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, sun visor, safety belt, air conditioner, warming light

Weight in kg:

Rated loading capacity at fifth wheel (kg):15660

Dead weight (kg):9210

Gross vehicle weight (kg):25000

Gross combination weight(kg):7000

Front axle loading capacity (kg):9000

Rear axle loading capacity (kg):2*16000

Performance Maximum driving speed(km/h):102(reference data)

Maximum gradeability (%):33

Minimum ground clearance(mm):265

Minimum turning radius (m):18.5

Fuel consumption(L/100km):40(reference data)



About SINOTRUK:

TITAN is authorised distributor of SINOTRUK, We produce New SINOTRUK Howo Trucks according to your order.

SINOTRUK is China's first heavy duty truck manufacturer, initially founded in 1956 and the cradle of China's heavy duty truck industry. SINOTRUK once manufactured China's first heavy duty truck, and it is China's first company to comprehensively introduce foreign heavy duty truck manufacturing technology of complete vehicle.

Today, SINOTRUK has developed into China's largest heavy duty truck manufacturing base and made significant contributions to the development of China's heavy duty truck industry and national economic growth.

SINOTRUK has been adhering to implementing independent innovations, carrying out its leading strategy in technologies and building its core competitiveness with intellectual property rights. It has the most patents in China's automotive industry.

SINOTRUK’s main truck models include HOWO, HOWO A7, HOHAN, main truck types include truck tractor, tipper truck, cargo truck, truck chassis, fuel tanker truck, water tank truck, and other special trucks.
