37 Ton Container Side Loader Trailer
37 Ton Container Side Loader Trailer

37 Ton Container Side Loader Trailer

67500 USD

The 37 ton container side loader trailer can transport 20/40ft container. Its technology can effectively solve the problem of no loading and unloading machinery.

Product description:

TITAN 37 ton container side loader trailer is used for loading and unloading 40ft container or 20ft container. TITAN 37 ton container side loader trailer have made work flexible, Save time and improve productivity for satisfied customers around the world. We adopt World famous brand parts of the side lifter cranes.

The 37 ton container side loader trailer technology can effectively solve the problem of no loading and unloading machinery. The military of many countries has been equipped with container loading trailers.

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea

37 Ton 40Ft Container Side Loader Trailer for Sale In Papua New Guinea



Specification:

Max. lifting capacity: 37Ton

Max.stabilizer outreach: 3200mm

Max.working range: 4000mm

Overall height: 2500mm

Overall length: 1020mm

Max.pressure of hydraulic system: 28Mpa

Dimension(L*W*H): 14100*2500*4200mm/7500*2500*4200mm

Axle: 3axle* 13 ton (220mm brake pads)

Tire: 12/8pcs, 12R22.5

Suspension: Heavy duty type mechanical spring suspension

Kingpin: 3.5 inch bolted type

Braking system: WABCO Emergency valve

Landing gear: JOST

Tow Chain: lgus (imported)

Power source: Power take-off (equipped)

Hydraulic pump: Gear type Casappa Italy

Direction control valves: AMCA Holand

Remote Control: NBB Germany



Advantage :

1. Timesaving and improve efficiency: TITAN Sidelifter can be productive all day, enabling loading, unloading and transporting containers by itself easily.

2. Flexible solutions: With the TITAN 40ft sidelifter container trailer, you get closer and can lift between trailers safely and with high precision.

3. Famous WABCO braking valve, JOST landing gear for the main chassis container skeleton trailer

4. Famous NBB Germany Remote Control, easy to operate

5. TITAN 40ft sidelifter container trailer adpots wireless remote control technology, loading container just takes 10 mins.



Service:

• Detailed operating instructions  also, we have the Video Explanation

• Overseas engineer to provide technical service

• You can reach us at any time and get a rapid response

•  Competent technical service,

• Rapid and safe deliveries of spare parts



Through this videos, you can learn about different types of container side loader trailers, as well as the process, testing, packaging and customer feedback, etc.
